Catatan Khusus
- Conveyor System with material loader
- Max Sheet Size : 600 x 400 mm
- Min Sheet Size : 210 x 297 mm
- Feeding System L Vacuum feed with clamps mounted on gantry
- Sheet Separation : Air Powered; Variable jet strem separation
- Sheet Alignment : Positioning Bars
- Unit Utama
Repeat Accuracy +/- 0.1 mm Sheet Separation Air Powered, Variable jet Stream Separation Feeding System Vacuum Feed with Clamps Mounted on Gantry Sheet Alignment Positioning Bars Max. Sheet Size 600 mm x 400 mm Min. Sheet Size 210 mm x 297 mm Mountable Tools Cut Through Knife, Kiss Cut Knife, Creasing Wheel, Camera Cutting System JWEI M5 Control System Blade Tungsten Steel Productivity 15 sec - 45 seconds per SRA3 Sheet (Average 30 seconds - depending upon complexity) Max. Cutting Speed 800 mm/s Auto Sheet Capacity < 10 cm Software (platform) JWCS Producitivity Controller File Form PLT, DXF, HP/GL Connection LAN Camera Registration System Industrial CCD Registration System Registration mark(s) Circle or Dot of 5 mm - 10 mm (At least; one on at top; another at bottom) Voltage 220 V +/- 10% 50 Hz Power 4 KW Dimensi Produk 2250 x 800 x 1100 mm Lain-lain Certificate : CE/SGS
| Spesifikasi | Keterangan |
|---|
